NORDAC FLEX Variable Frequency Drive - SK 200E

Name: NORDAC FLEX Variable Frequency Drive - SK 200E
Brand: NORD DRIVESYSTEMS
Availability: InStock

Greater flexibility for reduced TCO costs and greater ROI

Power range: 0.33 – 30 HP (0.25 – 22 kW)
Protection class: IP55, IP66
Wall-mount or motor-mount
Modular structure provides maximum flexibility

:	,

The NORDAC FLEX is NORD’s most flexible variable frequency drive. With their fully scalable functions, they can be tailored to all customer applications. Installation and maintenance of the NORDAC FLEX is incredibly fast and easy due to its wide range of functions and easy parameter transfer via EEPROM memory.

Power range: 0.33 – 30 HP (0.25 – 22 kW)
Single-phase: 110 – 120 V, 1/3-phase: 200 – 240 V, 3-phase: 380 – 500 V
Protection class: IP55, IP66
ATEX zone 22 3D
Wall-mounted, motor-mounted
Functional safety
SK CU4, SK TU4 plug-in control modules
SK CU4, SK TU4 extension modules

4x Digital In, 2x Digital Out, 2x Analog In
Optional In/Out extension
Functional safety: STO, SS1, SLS, SSR, SDI, SOS, SSM and PROFIsafe
Ethernet interface can be extended for each option module
Encoder interfaces: HTL, CANopen
Parameter structure compatible with all NORD variable frequency drives
Parameterization via plug-in control module, NORDCON software tool, or app
4 parameter sets can be switched directly online
Integrated brake rectifier for motor brake control
Motor brake management, lifting gear functionality
4-quadrant operation with integrated brake chopper
PLC-functionality for drive-related functions
V/f control, current vector control in open-loop and closed-loop mode
High precision regulation and large overload characteristics for synchronous and asynchronous motors
POSICON integrated positioning mode and synchronous operation
Integrated line filter

C020011_2015 - EAC Declaration of conformity - frequency inverters - Getriebebau NORD GmbH

Documentation Details

C020023_3018 - EAC Certificate of conformity for explosion proof frequency inverters NORD - No. 01109

Documentation Details

C020028_SK2xxE - EAC Certificate of conformity for frequeny inverter - NORDAC FLEX SK 200E

Documentation Details

C310401_CE - Declaration of Conformity - SK 180E ... 190E, SK 200E - 110V

Documentation Details

C310700_CE - Declaration of Conformity - SK 200E

Documentation Details

C310901_CE - Declaration of Conformity SK TIE5-BT-Stick.

Documentation Details

C312700 - Supplier’s declaration of conformity for frequency inverter SK 200E - Australia - ACMA

Documentation Details

C330701_Safety - Certificate for Frequency Inverter with safety switch off - SK 2x0E, size 1 - 3

Documentation Details

C330702_Safety - Certificate for Frequency Inverter with safety switch off - SK 2x0E, size 4

Documentation Details

C330703_Safety - Certificate for Frequency Inverter with safety switch off - SK 2x5E, size 1 - 3

Documentation Details

C330705_Safety - Certificate for Failsafe I/O module - SK TU4-PROFIsafe

Documentation Details

C432710_ATEX - Declaration of Conformity - Frequency Inverter SK 200E ATEX 2014/34/EU

Documentation Details

Symach Palletizer
